Single Diaphragm Pressure Gauge

Single Diaphragm Pressure Gauge
Single Diaphragm Pressure Gauge
Product Code : D101
Brand Name : G. M . E
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
  • Minimum Order Quantity
Trade Information
  • Payment Terms
  • Cash Advance (CA), Cash in Advance (CID), Cheque, Others
  • Delivery Time
  • 2 Week
  • Packaging Details
  • corrugated box
  • Main Domestic Market
  • Maharashtra
Product Description

We are a renowned trader of Single Diaphragm Differential Pressure Gauge to our highly respected clients. It is made using tested quality stainless steel and advanced technology and machinery at our vendors unit. We conduct quality checks on various parameters to ensure serving our clients with a defect free range of Single Diaphragm Differential Pressure Gauge. This has gained us huge applaud from our clients among our competitors. It is available at highly economical prices in the market and strive to make timely delivery.

Specifications:

  • Model D101
  • Max. static pressure 25 bar
  • Nominal size 100 mm, 115mm or 150 mm
  • Accuracy: Class 2.5(2.5%)

Features:

  • Stainless steel case and wetted parts
  • Static pressure 25 bar
  • Protection IP65
  • Dry or liquid filled

Ranges

  • 0 ... 250 mmWC up to 0 ... 10 kg/cm2

Applications :

  • Chemical and petrochemical industry
  • Machine and apparatus construction
  • Food and beverage industry
  • Pulp and paper industry

Technical specification

D101

Dial size [mm]

100

115

150

Construction

Cylindrical case with bayonet ring.

Measuring principle
Range[mmWC]
[kg/cm2]
Max. static pressure [kg/cm2]
Overload capability
Pressure type

Diaphragm, safety design, solid front not required
250 400 600 1000 1600 2500 4000 5000
0,6 1 1.6 2.5 4 6 10
25 bidirectional only
130 % F.S., short time
Differential

Process connection

1/4" 1/2" NPT (F), 1/4" 3/8" 1/2" BSP / NPT (M), M20x1.5(M), others on request

Connection location

Lower

Material
Pressure connection
Pressure chamber
Measuring membrane
Case/bayonet ring
Window
Dial
Pointer


Stainless steel 316
Stainless steel 316, Viton-ring
Stainless steel 316L
Stainless steel 304, optional 316L
Laminated safety glass optional acrylic glass
Aluminum, black markings on white background
Aluminum, black, optional Micrometer Adjustment

Accuracy calibrated ascending

Class 2.5 (2.5 % F.S.)

Permissible
Ambient temperature
Medium temperature
Storage temperature
Effect


-20 ... 80 °C
Max. 100 °C
-40 ... 60 °C
Max. 0,3 % / 10 K

Protection

IP65

Filling liquids

Glycerin, silicone, others on request

Mounting

Wall mounting, optional 2" pipe mounting, others on request

Weight dry/filled [kg]


Accessories, options

3 or 5 way remote or direct mounted manifolds, electric contacts
