Glycerin Filled Pressure Gauges

Glycerin Filled Pressure Gauges
Glycerin Filled Pressure Gauges
Product Code : GFB
Brand Name : G. M . E
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
Product Description

Utility pressure gauges

Model PG121
Nominal size 100 mm, 150mm and 250mm
Accuracy: Class 2.5 (2.5%)

Features :

  • Rugged construction
  • Protection IP54
  • Overload protection 130 %
  • Standard dial dual scale (psi, kg/cm2)
  • Dry

Ranges :

  • -30 in. Hg ... 0 psi up to 0 ... 10,000 psi

Applications :

  • Heating and ventilation
  • Machine and apparatus construction
  • Air filters and regulators
  • Valve positioners and compressors

Technical specification

PG121

Dial size in mm

100

150

250

Construction

Open front with push-in ring

Measuring principle
Range in psi
“Hg / psi
Overpressure limit
Pressure type

Bourdon tube
10 15 20 30 50 60 100 150 200 250 300 400 500 600 800 1000 1500 2000 3000 4000 5000 6000 8000 10000
-30”/0 -30”/15 -30”/30 -30”/60 -30”/100 -30”/150 -30/200
130 % F.S., short time.
Gauge, vacuum and compound

Process connection

1/4” 3/8” 1/2” BSP / NPT (M) , M20x1.5 (M)

Connection location

Lower, back

Material
Pressure connection
Tube
Case/ring
Window
Dial
Pointer
Movement

Brass
Bronze for ranges ≤ 1000 psi, SS316 for ranges > 1000psi
Black finished steel case
Instrument glass
Aluminum, black markings on white background
Aluminum, black
Brass

Accuracy

Class 2.5 (2.5%)

Permissible
Ambient temperature
Medium temperature
Storage temperature
Effect

-25 ... 60 °C
Max. 65 °C
-40 ... 65 °C
Max. 0,3 % / 10 K

Protection according

IP54

Mounting

Standard stem, optional panel, surface

Weight dry in kg


Trade Information
  • Payment Terms
  • Cash Advance (CA), Cash in Advance (CID), Cheque, Others
  • Delivery Time
  • 2 Week
  • Packaging Details
  • corrugated box
  • Main Domestic Market
  • Maharashtra
